Motion Sensor

Better motion detection and smart home connection

Vivint motion sensors provide complete coverage around the clock. When your system’s armed, your motion sensors will trigger a motion alarm, alert our 24/7 monitoring team, and notify you immediately.

Smarter motion detectors

Be alerted to unexpected movement with motion sensors designed to do more.

  • Vivint Motion Sensor
    Maximum Protection

    Covers an area as big as 40’ x 50’ with a 75° field of view. Wider coverage than any other motion sensor on the market.

  • Shield with a check mark inside
    Rapid and Reliable

    Vivint wireless motion sensors use infrared technology to detect body heat, so you get quick, accurate detection, day or night.

  • Battery Icon
    Battery powered

    With a 5-year battery life and innovative settings that prevent false alarms, Vivint motion sensors are durable and versatile.

Smart home integration

Motion sensors make home automation easy

Vivint motion sensors can communicate directly with your Smart Thermostat, Smart Lighting, and security cameras to adjust temperature, turn off lights, or activate recording. Customize your coverage on the Smart Hub or Vivint app.

pet accommodation

Pet-friendly motion detection

No false alarms here. Vivint motion sensors are equipped with two pet-adaptive settings that allow you to adjust sensitivity levels according to your pet’s size. Let your pet run free, we’ll catch what’s important.

Motion sensor specs

COLOR
White
SIZE
3.2″ h x 2.8″ w x 2.0″ d
FREQUENCY
345 MHz
MOUNTING
Screws and bracket
BATTERY
2 CR123A batteries
BATTERY LIFE
2-5 years
PROTECTION PLAN
1 year or the length of your Vivint Service Agreement, whichever is longer.
Other
40’ d x 50’ w max protection
75° field of view coverage
2 pet immunity settings
Battery life depends on traffic in the home
optimize installation

Perfect placement by the pros

Not sure where to install your motion sensors? Not a problem. Vivint security experts will help determine the best areas to install motion sensors in your unique home.

WHY VIVINT

Installed by the pros, perfectly

Our certified smart home pros deal with wiring, syncing devices, and placement, ensuring that every door, window and blind spot is covered. More good news: professional installation is included in your smart home package.

Frequently asked Motion Sensor questions

Where to place motion sensors?

Placement is key to making sure your motion sensors are effective, but all homes are different, so we recommend consulting with a Vivint security expert about where to place them on your property. Vivint wireless motion sensors have a wide range, so walls and ceilings are ideal installation spots for motion detectors. An outdoor motion sensor installed near your front door may act as a deterrent for potential intruders, seeing as most burglars check the front door before trying other entry points. A professional installer can provide valuable input regarding positioning and range of detection.

Read more tips for placing motion sensors in and around your home.

What do motion sensors do?

Motion sensors are small security devices that are mounted on the wall or ceiling. When your security system is armed and movement is detected in the sensor’s field of vision, the motion sensor activates the motion alarm.

Learn more about the various types of motion sensors and how they work.

Does light trigger motion sensors?

Residential homes are most commonly equipped with Passive Infrared (PIR) Motion Sensors, which detect infrared energy released as heat from humans and animals. So, a PIR motion sensor could potentially be triggered by light but is only likely to react when placed next to an extremely hot light bulb, a heating vent, a radiator, or another strong heat source.

Motion detectors can be used to turn lights on, activate recording on security cameras, and set off burglar alarms. Vivint offers two wireless motion detectors that use infrared technology and feature a 90-degree look-down, ensuring intruders cannot pass by unnoticed.

Learn more about the difference between PIR motion sensors, photosensors, and active motion sensors.

How do motion sensors work in the dark?

Motion sensors will work in the dark, as long as the type of motion sensors you’re using doesn’t use images to detect motion. For example, instead of relying on images, Vivint Motion Sensors use infrared technology to detect body heat, so they are highly effective both during the day and in the middle of the night.

Though motion detectors work just as well in the dark, learn why it’s important to keep your home well-lit.

What is a motion sensor alarm?

A motion sensor alarm is the alarm that sounds when a motion sensor is triggered. With Vivint, all of your security devices connect seamlessly on one simple platform, which means your motion sensors communicate directly with your alarm system and control panel. When the system is armed and motion is detected, your motion sensors will trigger the motion sensor alarm, alert you on the Vivint app, and contact our 24/7 monitoring team.

What triggers a motion sensor?

When it comes to the technology used to activate a motion sensor and motion sensor alarm, there are several different types. Each works in a different way. Some of the most common types of motion detectors include:

Passive Infrared motion sensors (PIR) – Most commonly used in home security motion sensors, a PIR sensor detects body heat in its field of vision.

Active motion sensors – Otherwise known as Microwave motion sensors, this type of sensor emits microwave pulses to a defined area, then measures the amount of time it takes the waves to bounce back. If a person or object interferes with the signal, it delays the return time, setting off the motion alarm.

Dual-technology motion sensors – Typically consisting of both microwave and PIR sensors, dual-technology motion detectors attempt to reduce false alarms because both sensors must go off to trigger the motion alarm. Pets have been known to trigger false alarms, but there are specific ways to prevent this.

There are pros and cons to each type of motion sensor, but see why the Vivint wireless motion sensors are the right choice for your home.
